Запчасти Komatsu PC240LC-10 T- ЦИЛИНДР КОВША РАБОЧЕЕ ОБОРУДОВАНИЕ

|$1

707-E1-00960

CYLINDER ASSEMBLY

1

721-13-13230

CYLINDER

2

707-58-90E60

ROD, PISTON

3

707-76-80431

BUSHING

4

07145-00080

SEAL, DUST

5

07020-00000

FITTING, GREASE

6

707-76-80020

BUSHING

7

20Y-70-23230

SEAL, DUST

8

07020-00000

FITTING, GREASE

9

707-27-13750

CYLINDER HEAD

10

07179-13104

RING, SNAP

11

707-56-90740

SEAL, DUST

12

707-52-90681

BUSHING

13

707-51-90860

PACKING, ROD

14

707-51-90650

RING, BUFFER

15

07000-B5120

O-RING

16

707-35-31210

RING, BACK-UP

17

01010-81875

BOLT

18

707-41-11840

WASHER

19

707-75-90110

RING, SNAP

20

707-36-13780

PISTON

21

707-44-13150

RING, PISTON

22

707-39-13150

RING, WEAR

23

707-44-13911

RING

24

07000-B5080

O-RING

25

707-35-30800

RING, BACK-UP

26

01310-01216

SCREW

27

707-86-67820

TUBE

28

07372-21045

BOLT

29

01643-51032

WASHER

30

07372-21060

BOLT

31

01643-51032

WASHER

32

07000-13030

O-RING

33

707-88-22640

BRACKET

34

707-88-21331

BAND

35

07372-21035

BOLT

36

01643-51032

WASHER

37

07283-32738

CLIP, PIPE

38

01597-01009

NUT

39

01643-31032

WASHER

40

07371-30640

FLANGE, SPLIT

41

707-88-33030

CAP

42

07371-31049

FLANGE, SPLIT

43

707-88-33040

CAP

|$45

707-99-48710

SERVICE KIT, BUCKET CYLINDER
