Запчасти Komatsu PC240LC-10 T- ЦИЛИНДР РУКОЯТИ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-E1-00180

CYLINDER ASSEMBLY

1

721-13-14010

CYLINDER

2

721-58-10070

ROD, PISTON

3

707-76-80431

BUSHING

4

07145-00080

SEAL, DUST

5

707-76-80431

BUSHING

6

07145-00080

SEAL, DUST

7

07020-00000

FITTING, GREASE

8

707-71-35150

COLLAR

9

707-71-71020

PLUNGER

10

07000-B5130

O-RING

11

707-35-31310

RING, BACK-UP

12

707-71-80320

PLUNGER

13

04260-00635

BALL, STEEL

14

707-71-91270

CAP

15

707-27-14690

HEAD, CYLINDER

16

707-56-10740

SEAL, DUST

17

07179-13114

RING, SNAP

18

707-52-90781

BUSHING

19

707-51-10860

PACKING, ROD

20

707-51-10650

RING, BUFFER

21

707-35-31310

RING, BACK-UP

22

07000-B5130

O-RING

23

01010-81875

BOLT

24

707-41-11840

WASHER

25

707-75-10160

RING, SNAP

26

707-36-14650

PISTON

27

707-44-14150

RING, PISTON

28

707-39-14110

RING, WEAR

29

707-35-30900

RING, BACK-UP

30

07000-B5090

O-RING

31

707-44-14910

RING

32

01310-01216

SCREW

33

707-83-13010

VALVE

34

07750-01628

SPRING

35

707-87-14070

PLUG

36

07002-12034

O-RING

37

707-86-67810

TUBE

38

707-88-22630

BRACKET

39

07372-21060

BOLT

40

01643-51032

WASHER

41

07372-21045

BOLT

42

01643-51032

WASHER

43

07000-13030

O-RING

44

707-88-28090

BRACKET

45

707-88-28140

BAND

46

707-88-21321

BAND

47

07372-21035

BOLT

48

01643-51032

WASHER

49

07283-32738

CLIP, PIPE

50

01597-01009

NUT

51

01643-31032

WASHER

52

07371-31049

FLANGE, SPLIT

53

707-88-33040

CAP

54

07371-30640

FLANGE, SPLIT

55

707-88-33030

CAP

|$56

707-99-59430

SERVICE KIT, ARM CYLINDER
