Запчасти Komatsu PC240LC-10 T- ЦИЛИНДР СТРЕЛЫПРАВ. РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-E1-00200

CYLINDER ASSEMBLY, RIGHT SIDE

1

721-13-13160

CYLINDER

2

707-58-95280

ROD, PISTON

3

707-76-80431

BUSHING

4

07145-00080

SEAL, DUST

5

707-76-80431

BUSHING

6

07145-00080

SEAL, DUST

7

707-71-35180

COLLAR

8

707-35-31260

RING, BACK-UP

9

07000-B5125

O-RING

10

707-71-71010

PLUNGER

11

707-27-13850

HEAD, CYLINDER

12

707-56-95740

SEAL, DUST

13

07179-13109

RING, SNAP

14

707-52-90721

BUSHING

15

707-51-95030

PACKING, ROD

16

707-51-95650

RING, BUFFER

17

707-35-31260

RING, BACK-UP

18

07000-B5125

O-RING

19

01010-81875

BOLT

20

707-41-11840

WASHER

21

707-75-95030

RING, SNAP

22

707-36-13771

PISTON

23

707-44-13250

RING, PISTON

24

707-39-13530

RING, WEAR

25

707-44-13920

RING, BACK-UP

26

01310-01216

SCREW

27

07000-B5085

O-RING

28

707-35-30850

RING, BACK-UP

29

707-86-69030

TUBE, R.H.

30

707-86-00780

TUBE, R.H.

31

707-88-29840

BRACKET, R.H.

32

07372-21060

BOLT

33

01643-51032

WASHER

34

07372-21045

BOLT

35

01643-51032

WASHER

36

707-88-21261

BAND

37

07000-13030

O-RING

38

07372-21035

BOLT

39

01643-51032

WASHER

40

07283-32738

CLIP, PIPE

41

01597-01009

NUT

42

01643-31032

WASHER

43

07371-30640

FLANGE, SPLIT

44

707-88-33030

CAP

45

07371-31049

FLANGE, SPLIT

46

707-88-33040

CAP

47

07283-33442

CLIP, PIPE

48

07000-13035

O-RING

49

07020-00000

FITTING, GREASE

|$50

707-99-50580

SERVICE KIT, BOOM CYLINDER
