Запчасти Komatsu PC240LC-10 K- КАБИНА АКСЕССУАРЫ OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$1

2A5-53-00085

CAB ASSEMBLY

1

2A5-53-12561

COVER

2

09416-10200

BUTTON

3

20Y-53-12421

COVER

4

09416-10200

BUTTON

5

20Y-53-12431

COVER

6

208-53-13270

RIVET

7

20Y-53-12710

SEAL

8

20Y-53-12442

COVER

9

09416-10200

BUTTON

10

20Y-53-12710

SEAL

11

2A5-53-11280

SEAL

12

2A5-53-11291

COVER

13

20Y-53-12310

COLLAR

14

01435-80616

BOLT

15

01435-00612

BOLT

16

01435-00616

BOLT

17

22B-54-17380

HAMMER

18

20Y-53-12472

COVER

19

20Y-53-12310

COLLAR

20

01245-00616

SCREW, HEXAGON SOCKET HEAD

21

01643-70623

WASHER

22

01435-00612

BOLT

23

20Y-53-13870

SEAL

24

2A5-06-11940

CABLE

25

2A5-06-12131

CAP

26

2A5-53-12580

NUT

27

08059-00515

CLIP

28

08051-00801

CLIP

29

205-54-51250

HANGER

30

01370-30416

SCREW

31

208-53-12991

HOLDER

32

208-53-12980

PLATE

33

01023-20616

SCREW

34

2A5-53-11321

COVER

35

2A5-53-11G90

HINGE, WELDED

36

2A5-53-11330

TRIM

37

2A5-53-11141

LOCK ASSEMBLY

38

01435-40610

BOLT
