Запчасти Komatsu PC240LC-10 H- ЛИНИЯ ПОДАЧИ C ПРОХОДНЫМ ФИЛЬТРОМ ГИДРАВЛИКА

1

2A5-62-13962

HOSE

2

07000-13032

O-RING

3

2A5-62-13952

HOSE

4

07000-13032

O-RING

5

07371-31049

FLANGE, SPLIT

6

07372-21035

BOLT

7

01643-51032

WASHER

8

2A5-60-11241

FILTER ASSEMBLY

9

20Y-60-31430

ELEMENT

10

07000-12035

O-RING

11

21K-62-72790

RING, BACK-UP

12

07000-13035

O-RING

13

07371-31049

FLANGE, SPLIT

14

07372-21035

BOLT

15

01643-51032

WASHER

16

2A5-60-11251

FILTER ASSEMBLY

17

20Y-60-31430

ELEMENT

18

07000-12035

O-RING

19

21K-62-72790

RING, BACK-UP

20

07000-13035

O-RING

21

07371-31049

FLANGE, SPLIT

22

07372-21035

BOLT

23

01643-51032

WASHER

24

2A5-62-14310

PLATE

25

07371-30640

FLANGE, SPLIT

26

07372-21035

BOLT

27

01643-51032

WASHER

28

07372-21055

BOLT

29

01643-51032

WASHER

30

07371-31049

FLANGE, SPLIT

31

07372-21035

BOLT

32

01643-51032

WASHER

33

2A5-62-11262

HOSE

34

07000-13032

O-RING

35

2A5-62-11222

HOSE

36

07000-13032

O-RING

37

01011-81040

BOLT

38

01643-31032

WASHER
