Запчасти Komatsu PC240LC-10 H-8 ОСНОВН. ПОРШЕНЬ НАСОС ВНУТР. ЧАСТИ (8/) ГИДРАВЛИКА

|$0

708-2G-00310

PUMP ASSEMBLY

|$1

708-2G-01310

PUMP SUBASSEMBLY

1

708-2G-14610

SLIDER

|$3

708-2G-03310

VALVE ASSEMBLY

|$4

708-2G-03320

PISTON ASSEMBLY

2

NSS

PISTON

3

NSS

SCREW

4

708-2G-15320

SEAL

5

708-2L-45210

PLUG

6

708-2L-35760

BALL

7

708-2L-35770

PLUG

8

708-2L-35690

SEAL

9

708-2L-35280

PIN

10

708-2L-35860

SPOOL

11

708-2G-15290

RETAINER

12

708-2L-35641

SEAT

13

708-2G-14650

SPRING

14

708-2G-14670

SPRING

15

708-2L-35650

SEAT

16

708-2G-14660

SPRING

17

708-2G-14690

SCREW

18

07000-B3038

O-RING

19

708-2G-15230

RING, BACK-UP

20

708-2G-15260

SEAL

21

708-2L-35270

PLUG

22

07000-B2011

O-RING

23

07000-B2050

O-RING

24

708-2G-15310

RING

25

708-2G-14680

COVER

26

01580-10806

NUT

27

708-2L-35290

NUT

28

708-2G-15330

RING, WEAR

29

708-2L-45240

SEAL, RING

30

01010-61645

BOLT

31

01643-31645

WASHER
