Запчасти Komatsu PC240LC-10 H-7 ОСНОВН. ПОРШЕНЬ НАСОС ВНУТР. ЧАСТИ (7/) ГИДРАВЛИКА

|$0

708-2G-00310

PUMP ASSEMBLY

|$1

708-2G-01310

PUMP SUBASSEMBLY

1

708-2G-12620

SHAFT, REAR

2

708-2L-42250

BEARING

3

708-2E-05040

WASHER KIT

|$5

NSS

WASHER, T= 3.1 MM

|$6

NSS

WASHER, T= 3.0 MM

|$7

NSS

WASHER, T= 2.9 MM

|$8

NSS

WASHER, T= 2.8 MM

4

708-25-12790

RING, SNAP

|$10

708-2G-04650

BLOCK ASSEMBLY, REAR

5

NSS

BLOCK, CYLINDER

6

NSS

PLATE, VALVE

7

708-18-13230

PIN

8

04065-05820

RING, SNAP

9

708-2L-43130

SEAT

10

708-2G-13760

SPRING

11

708-2H-23141

SEAT

12

708-2G-13740

GUIDE, RETAINER

13

708-2L-43360

PIN

14

708-2G-13750

RETAINER, SHOE

15

708-2L-43311

PISTON SUBASSEMBLY

|$22

708-2G-04660

CRADLE ASSEMBLY

16

NSS

CRADLE

17

NSS

CAM, ROCKER

18

04020-01228

PIN

19

01252-61025

BOLT, HEXAGON SOCKET HEAD
