Запчасти Komatsu PC240LC-10 H- ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН ВНУТР. ЧАСТИ С -ДОПОЛН. АКТУАТОР (/) ГИДРАВЛИКА

|$0

723-47-29800

VALVE ASSEMBLY

|$1

723-40-73100

VALVE ASSEMBLY

1

NSS

BODY

2

NSS

SPOOL

3

723-40-72800

PLATE

4

702-21-61600

VALVE, PILOT

5

700-80-61260

O-RING

6

723-11-19960

O-RING

7

702-21-54180

SCREW

8

702-16-55610

O-RING

9

723-46-15111

CASE

10

07430-71380

O-RING

11

723-40-71330

RETAINER

12

723-40-71340

SPRING

13

723-40-71350

RETAINER

14

01252-60816

BOLT

15

723-40-71870

UNION

16

02896-11008

O-RING

17

07002-11423

O-RING

18

07040-11409

PLUG

19

07002-11423

O-RING

20

01252-60855

BOLT, HEXAGON SOCKET HEAD

21

01252-60635

BOLT, HEXAGON SOCKET HEAD

22

NSS

SPOOL ASSEMBLY

23

723-40-71850

SPRING

24

723-46-18720

O-RING

25

NSS

SPOOL

26

723-40-71390

SPRING

27

723-46-18720

O-RING

|$29

723-40-71900

VALVE ASSEMBLY

28

723-40-91600

VALVE ASSEMBLY, RELIEF

29

702-16-53920

O-RING

30

07002-11623

O-RING

31

NSS

BLOCK

32

NSS

SPOOL

33

NSS

SPRING

34

702-21-55620

PLUG

35

07002-11423

O-RING

36

702-21-55710

SEAT

37

702-21-55720

SPRING

38

04260-00793

BALL

39

07000-11009

O-RING

40

NSS

PLUG
