Запчасти Komatsu PC240LC-10 ЦИЛИНДР СТРЕЛЫ, ВНУТР. ЧАСТИ, ЛЕВ. (№9-) ЦИЛИНДР СТРЕЛЫ, ЧАС. СМАЗКА INTERVAL

|$0

707-E1-00200

Cylinder Assembly

1

721-13-13160

Cylinder

2

707-58-95280

Rod, Piston

3

707-76-80431

Bushing

4

07145-00080

Seal, Dust, (Kit : K02)

5

707-76-80431

Bushing

6

07145-00080

Seal, Dust, (Kit : K02)

7

707-71-35180

Collar

8

707-35-31260

Ring, Back-up, (Kit : K02)

9

07000-B5125

O-ring, (Kit : K02)

10

707-71-71010

Plunger

11

707-27-13850

Head, Cylinder

12

707-56-95740

Seal, Dust, (Kit : K02)

13

07179-13109

Ring, Snap

14

707-52-90721

Bushing

15

707-51-95030

Packing, Rod, (Kit : K02)

16

707-51-95650

Ring, Buffer, (Kit : K02)

17

707-35-31260

Ring, Back-up

18

07000-B5125

O-ring

19

01010-81875

Bolt

20

707-41-11840

Washer

21

707-75-95030

Ring, Snap

22

707-36-13771

Piston

23

707-44-13250

Ring, Piston, (Kit : K02)

24

707-39-13530

Ring, Wear, (Kit : K02)

25

707-44-13920

Ring

26

01310-01216

Screw

27

07000-B5085

O-ring, (Kit : K02)

28

707-35-30850

Ring, Back-up, (Kit : K02)

29

707-86-69020

Tube

30

707-86-00770

Tube

31

707-88-51080

Bracket

32

07372-21060

Bolt

33

01643-51032

Washer

34

07372-21045

Bolt

35

01643-51032

Washer

36

707-88-21261

Band

37

07000-13030

O-ring, (Kit : K02)

38

07372-21035

Bolt

39

01643-51032

Washer

40

07283-32738

Clip, Pipe

41

01597-01009

Nut

42

01643-31032

Washer

43

07371-30640

Flange, Split

44

707-88-33030

Cap

45

07371-31049

Flange, Split

46

707-88-33040

Cap

47

07283-33442

Clip, Pipe

48

07000-13035

O-ring, (Kit : K02)
