Запчасти Komatsu PC240LC-10 СИСТЕМА ОХЛАЖДЕНИЯ, ЗАЩИТА ВЕНТИЛЯТОРА (№9-) СИСТЕМА ОХЛАЖДЕНИЯ

1

2A5-03-11831

Guard

2

01010-81020

Bolt

3

01643-31032

Washer

4

2A5-03-11842

Guard

5

01010-81020

Bolt

6

01643-31032

Washer

7

2A5-03-11852

Guard

8

01010-81020

Bolt

9

01643-31032

Washer

10

206-03-31391

Tube

11

01010-81245

Bolt

12

01643-31232

Washer

13

2A5-03-11681

Tube

14

01010-81245

Bolt

15

01643-31232

Washer

16

07283-34346

Clip

17

01643-31032

Washer

18

01597-01009

Nut

19

07000-13045

O-ring

20

07040-11409

Plug

21

07002-11423

O-ring

22

20Y-60-22210

Body

23

07002-11423

O-ring

24

6738-11-4320

Pipe

25

07043-70108

Plug

26

6738-11-4370

O-ring

27

6738-11-4380

Clamp

28

6738-11-4390

Nut

29

2A5-03-12111

Hose

30

04434-51612

Clip

31

11Y-09-11140

Clip

|$31

2A5-03-11791

Cover

32

Cover

33

2A5-03-11780

Sheet

34

01010-81020

Bolt

35

01643-31032

Washer

36

2A5-03-11861

Sheet

37

2A5-03-11870

Sheet

38

2A5-03-11881

Sheet

39

2A5-03-11891

Sheet

40

2A5-03-11920

Sheet

41

2A5-03-11930

Sheet

42

206-03-31470

Step

43

01010-81030

Bolt

44

01643-31032

Washer

45

20Y-979-6191

Sensor

46

20Y-979-6271

Bracket

47

01010-80616

Bolt

48

01643-30623

Washer

49

22U-03-31170

Shroud

50

01010-81030

Bolt

51

203-54-56970

Washer

52

21T-00-31710

Plate
