Запчасти Komatsu PC240LC-10 ПОДАЮЩ. ТРУБЫ (№9-) ПОДАЮЩ. ТРУБЫ, C ПРОХОДНЫМ ФИЛЬТРОМ

1

2A5-62-13962

Hose

2

07000-13032

O-ring

3

2A5-62-13952

Hose

4

07000-13032

O-ring

5

07371-31049

Flange, Split

6

07372-21035

Bolt

7

01643-51032

Washer

8

2A5-60-11241

Filter Assembly

9

20Y-60-31430

Element

10

07000-12035

O-ring

11

21K-62-72790

Ring, Back-up

12

07000-13035

O-ring

13

07371-31049

Flange, Split

14

07372-21035

Bolt

15

01643-51032

Washer

16

2A5-60-11251

Filter Assembly

17

20Y-60-31430

Element

18

07000-12035

O-ring

19

21K-62-72790

Ring, Back-up

20

07000-13035

O-ring

21

07371-31049

Flange, Split

22

07372-21035

Bolt

23

01643-51032

Washer

24

2A5-62-14310

Plate

25

07371-30640

Flange, Split

26

07372-21035

Bolt

27

01643-51032

Washer

28

07372-21055

Bolt

29

01643-51032

Washer

30

07371-31049

Flange, Split

31

07372-21035

Bolt

32

01643-51032

Washer

33

2A5-62-11262

Hose

34

07000-13032

O-ring

35

2A5-62-11222

Hose

36

07000-13032

O-ring

37

01011-81040

Bolt

38

01643-31032

Washer
