Запчасти Komatsu PC240-8K ГИДРАВЛ МАСЛ. БАК(№-) ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
1
20Y-60-41112NK
Tank
2
203-60-31100
Elbow Assembly
3
203-60-31160
Tube
4
07044-12412
Plug, with Magnet
5
07002-12434
O-ring
6
02781-00628
Union
7
02896-11018
O-ring
8
07002-12434
O-ring
9
02782-10522
Elbow
10
02896-11015
O-ring
11
07002-12434
O-ring
12
20Y-62-45690
Tee
13
02896-11009
O-ring
14
02896-11008
O-ring
15
07002-12034
O-ring
16
02782-10311
Elbow
17
02896-11009
O-ring
18
07002-11423
O-ring
19
21K-62-72491
Tee
20
02896-11018
O-ring
21
02789-00628
Plug, Face Seal Type
22
07002-12434
O-ring
23
20Y-62-15660
Adapter
24
07002-12034
O-ring
25
02782-10516
Elbow
26
02896-11015
O-ring
27
07002-12034
O-ring
28
02783-10315
Elbow
29
02896-11009
O-ring
30
07002-12034
O-ring
31
07040-12012
Plug
32
07002-12034
O-ring
33
207-60-71181
Element
34
20Y-60-31140
Strainer
35
20Y-60-31131
Valve Assembly
36
20Y-60-21240
Spring
37
22U-60-21232NK
Cover
38
07000-15195
O-ring
39
01010-81230
Bolt
40
01643-31232
Washer
|41
20Y-60-31171
Strainer Assembly
41
207-60-61150
Rod Assembly
42
20Y-60-21320
Holder
43
12R-60-11230
Spring
44
22B-60-11160
Strainer
45
20Y-60-41162NK
Cover
46
07000-15160
O-ring
47
01010-81230
Bolt
48
01643-31232
Washer
49
17A-60-11310
Cap Assembly
50
20Y-60-21470
Element
51
208-60-71180NK
Neck
52
20Y-60-21340
Gasket
53
01252-70516
Bolt, Hexagon Socket Head
54
01601-20513
Washer, Spring
55
07285-00155
Clip, Hose
56
07270-61411
Tube
57
205-00-73360
Plate
58
01010-81635
Bolt
59
01643-31645
Washer
Выбрано товаров: 60
