Запчасти Komatsu PC240-8K ЦИЛИНДР СТРЕЛЫ(/)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

707-01-0H850

Cylinder Assembly, RHS

1

707-13-13920

Cylinder

2

707-76-80431

Bushing

3

07145-00080

Seal, Dust, (Kit : C05)

4

707-58-95280

Rod, Piston

5

707-76-80431

Bushing

6

07145-00080

Seal, Dust, (Kit : C05)

7

707-27-13850

Cylinder Head

8

07179-13109

Ring, Snap

9

707-56-95510

Seal, Dust, (Kit : C05)

10

707-52-90721

Bushing

11

707-75-95030

Ring, Snap

12

707-51-95030

Packing, (Kit : C05)

13

07000-15125

O-ring, (Kit : C05)

14

707-35-91370

Ring, Back-up, (Kit : C05)

15

707-51-95650

Ring, (Kit : C05)

16

01010-81875

Bolt

17

707-41-11840

Washer

18

707-36-13771

Piston

19

707-44-13250

Ring, Piston, (Kit : C05)

20

707-39-13530

Ring, Wear, (Kit : C05)

21

707-44-13920

Ring

22

707-71-71010

Plunger

23

07000-15085

O-ring, (Kit : C05)

24

707-35-90960

Ring, Back-up, (Kit : C05)

25

01310-01216

Screw

26

707-71-35010

Collar

27

707-35-91370

Ring, Back-up, (Kit : C05)

28

07000-15125

O-ring, (Kit : C05)

29

707-86-67850

Tube, RHS

30

07372-21060

Bolt

31

01643-51032

Washer

32

07372-21045

Bolt

33

01643-51032

Washer

34

07000-13030

O-ring, (Kit : C05)

35

707-88-28160

Bracket, RHS

36

707-88-21261

Band

37

07372-21035

Bolt

38

01643-51032

Washer

39

07283-32738

Clip, Pipe

40

01597-01009

Nut

41

01643-31032

Washer

42

206-62-73460NK

Tube

43

07000-13030

O-ring

44

07372-21035

Bolt

45

01643-51032

Washer

46

702-21-08330

Valve, Pilot

47

07000-13030

O-ring

48

07372-21060

Bolt

49

01643-51032

Washer

50

07372-21050

Bolt

51

01643-51032

Washer

52

707-88-33030

Cap

53

07371-30640

Flange, Split

54

07372-21035

Bolt

55

01643-51032

Washer

56

07283-32738

Clip, Pipe

57

01597-01009

Nut

58

01643-31032

Washer
