Запчасти Komatsu PC240-8K ЦИЛИНДР СТРЕЛЫ(/)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ
№
Артикул
Название
Примечание
Количество
|1
707-01-0H850
Cylinder Assembly, LHS
1
707-13-13920
Cylinder
2
707-76-80431
Bushing
3
07145-00080
Seal, Dust, (Kit : C05)
4
707-58-95280
Rod, Piston
5
707-76-80431
Bushing
6
07145-00080
Seal, Dust, (Kit : C05)
7
707-27-13850
Cylinder Head
8
07179-13109
Ring, Snap
9
707-56-95510
Seal, Dust, (Kit : C05)
10
707-52-90721
Bushing
11
707-75-95030
Ring, Snap
12
707-51-95030
Packing, (Kit : C05)
13
07000-15125
O-ring, (Kit : C05)
14
707-35-91370
Ring, Back-up, (Kit : C05)
15
707-51-95650
Ring, (Kit : C05)
16
01010-81875
Bolt
17
707-41-11840
Washer
18
707-36-13771
Piston
19
707-44-13250
Ring, Piston, (Kit : C05)
20
707-39-13530
Ring, Wear, (Kit : C05)
21
707-44-13920
Ring
22
707-71-71010
Plunger
23
07000-15085
O-ring, (Kit : C05)
24
707-35-90960
Ring, Back-up, (Kit : C05)
25
01310-01216
Screw
26
707-71-35010
Collar
27
707-35-91370
Ring, Back-up, (Kit : C05)
28
07000-15125
O-ring, (Kit : C05)
29
707-86-67840
Tube, LHS
30
07372-51060
Bolt
31
01643-51032
Washer
32
07372-51045
Bolt
33
01643-51032
Washer
34
07000-13030
O-ring, (Kit : C05)
35
707-88-28150
Bracket, LHS
36
707-88-21261
Band
37
07372-21035
Bolt
38
01643-51032
Washer
39
07283-32738
Clip, Pipe
40
01597-01009
Nut
41
01643-31032
Washer
42
206-62-73450NK
Tube
43
07000-13030
O-ring
44
07372-21035
Bolt
45
01643-51032
Washer
46
702-21-08330
Valve, Pilot
47
07000-13030
O-ring
48
07372-21060
Bolt
49
01643-51032
Washer
50
07372-21050
Bolt
51
01643-51032
Washer
52
707-88-33030
Cap
53
07371-30640
Flange, Split
54
07372-21035
Bolt
55
01643-51032
Washer
56
07283-32738
Clip, Pipe
57
01597-01009
Nut
58
01643-31032
Washer
Выбрано товаров: 59
