Запчасти Komatsu PC240-8K МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА (/)(№-) ХОД СИСТЕМА И ITS КОМПОНЕНТЫ

|1

206-27-00422

Final Drive Assembly

|1

708-8F-00192

Motor Assembly

|1

Case Subassembly

1

708-8F-31140

Case, Motor

2

708-21-12541

Plug

|3

Cover Subassembly, End

3

708-8F-31540

Cover, End

4

708-8F-36160

Spool

5

708-8F-31620

Plug

6

708-21-12541

Plug

7

708-8F-34210

Spool

8

Spring

9

708-8H-11530

Plug

10

07002-11423

O-ring

11

20B-27-11210

Bleeder

|12

702-73-02112

Valve Assembly, Relief

12

702-73-11312

Sleeve

13

702-73-11320

Valve

14

702-73-11330

Spring

15

723-46-48910

Seal

16

702-73-11340

Screw

17

702-72-11170

Nut

18

708-8F-36611

Spring

19

708-8F-36120

Ring

20

708-8H-36121

Spring

21

708-8F-36311

Cover

22

07000-13040

O-ring

23

700-93-11320

O-ring

24

07000-11009

O-ring

25

01252-61235

Bolt, Hexagon Socket Head

26

708-8F-34120

Valve

27

722-10-91130

Spring

28

708-8F-34110

Plug

29

07002-11823

O-ring

30

708-8E-16180

Valve

31

708-8F-31660

Plug

32

07000-11006

O-ring

33

07001-01006

Ring, Back-up

34

07002-11223

O-ring

35

708-8F-31610

O-ring

36

07000-11009

O-ring

37

Pin

38

708-8F-31210

Bolt
