Запчасти Komatsu PC240-8K КАБИНА (/)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-43-42312

Frame, RHS

2

01010-D1230

Bolt

3

01643-71232

Washer, Flat

4

20Y-43-41631

Sheet

5

22U-43-23251

Sheet

6

22U-43-23290

Clip

7

20Y-43-41323

Cover

8

20Y-43-41661

Sheet

9

01010-80616

Bolt

10

01643-30623

Washer

11

20Y-43-41290

Collar

12

20Y-43-41332

Cover

13

01245-00616

Screw, Hexagon Socket Head

14

01643-70623

Washer

15

01010-80616

Bolt

16

01643-30623

Washer

17

01435-00612

Bolt

18

20Y-43-41290

Collar

19

20Y-43-41353

Cover

20

01245-00616

Screw, Hexagon Socket Head

21

01643-70623

Washer

22

20Y-43-41290

Collar

23

01245-00616

Screw, Hexagon Socket Head

24

01643-70623

Washer

25

09415-02512

Cap

26

08086-20000

Switch, Starting

27

20Y-43-41740

Plate

28

20Y-43-41750

Washer

29

20Y-43-41790

Washer

30

20Y-43-41671

Sheet

31

08034-20519

Band

32

22U-06-22380

Potentiometer

33

22U-06-22460

Spring

34

20Y-43-41780

Knob

35

20Y-06-42110

Switch

36

20Y-06-42121

Switch, Light

37

20Y-06-42190

Cover

38

20Y-06-48131

Wire Harness

39

01023-10508

Screw

40

01601-20513

Washer, Spring

41

22U-43-23260

Clip

42

04434-51710

Clip

43

01010-81016

Bolt

44

01643-31032

Washer

45

04434-51410

Clip

46

01010-81016

Bolt

47

01643-31032

Washer
