Запчасти Komatsu PC240-8K СТРЕЛА И РУКОЯТЬ HOLDING КЛАПАН КОНТУР (/)(№-) ГИДРАВЛИКА

|1

702-21-08340

Valve, Pilot

1

702-21-38120

Valve Body

2

702-21-38230

Spool

3

702-21-38510

Case

4

702-21-38420

Retainer, 2.0mm

|4

702-21-38550

Retainer, 1.7mm

|4

702-21-38560

Retainer, 2.3mm

5

702-21-38430

Flange

6

702-21-38440

Spring

7

702-21-38540

Spring

8

702-21-38460

O-ring

9

702-21-38470

O-ring

10

702-21-38480

Plug

11

01252-30825

Bolt, Hexagon Socket Head

12

01252-30835

Bolt, Hexagon Socket Head

13

01252-30620

Bolt, Hexagon Socket Head

14

01641-20608

Washer, Flat

15

07000-02021

O-ring

16

709-74-92810

Valve

17

709-75-92220

Spring

18

700-93-11320

O-ring

19

700-93-11330

Ring, Back-up

20

723-40-91500

Valve Assembly, Relief

21

700-80-64220

Ring

22

700-22-11410

O-ring

23

709-25-11390

O-ring
