Запчасти Komatsu PC230NHD-8K БЫСТРОСЪЕМН. МЕХ-М КЛАПАН (2-СЕКЦИОНН. СТРЕЛА) (ШАССИ) H ГИДРАВЛИКА

|1

20J-62-13141

VALVE

1

20J-06-11640

COIL

2

20J-60-11590

VALVE

3

20J-60-11580

VALVE

4

01010-81085

BOLT

5

01643-31032

WASHER

6

07040-11409

PLUG

7

07002-11423

O-RING

8

20J-06-11580

SWITCH, PRESSURE

|8

07040-11409

PLUG

9

07002-11423

O-RING

10

02781-0031D

NIPPLE

11

07002-11423

O-RING

12

02896-11009

O-RING

13

02782-10210

ELBOW

14

07002-11423

O-RING

15

02896-11008

O-RING

16

07040-11007

PLUG

17

07002-11023

O-RING

18

02783-10210

ELBOW

19

02896-11008

O-RING

20

07002-11423

O-RING

21

02783-10210

ELBOW

22

02896-11008

O-RING

23

07002-11423

O-RING

24

207-62-72120

ELBOW

25

07002-11423

O-RING

26

02896-11008

O-RING

27

20Y-62-K6891

BRACKET

28

01010-81255

BOLT

29

01643-31232

WASHER

30

20Y-62-K6870

BRACKET

31

01010-81225

BOLT

32

01643-31232

WASHER

33

20Y-62-K6880

BRACKET

34

01010-81225

BOLT

35

01643-31232

WASHER

36

02777-00315

EPH HOSE

37

02777-00207

EPH HOSE

38

20Y-62-K6912

HOSE

|38

20Y-62-K7181

HOSE

|38

20Y-62-K7180

HOSE

39

20Y-62-K6922

HOSE

|39

20Y-62-K7191

HOSE

|39

20Y-62-K7190

HOSE

40

04434-51712

CLIP

41

07095-20211

CUSHION

42

01010-81225

BOLT

43

01643-31232

WASHER

44

04434-51712

CLIP

45

07095-20211

CUSHION

46

01010-81225

BOLT

47

01643-31232

WASHER

48

04434-52512

CLIP

49

04434-51712

CLIP

50

01010-81275

BOLT

51

01643-31232

WASHER

52

04434-51512

CLIP

53

15497-91480

COLLAR

54

08192-22100

CONNECTOR, BLANKING

55

08192-12300

CONNECTOR, BLANKING

56

08191-00770

SEALING PLUG, BLANKING

57

08192-22100

CONNECTOR, BLANKING

58

08192-12300

CONNECTOR, BLANKING

59

08191-00770

SEALING PLUG, BLANKING

60

08034-00519

BAND
