Запчасти Komatsu PC230NHD-8K DIESEL ЧАСТЬICULATE ФИЛЬТР. И КРЕПЛЕНИЕ (№K-) B КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

20Y-01-K2231

MUFFLER ASSEMBLY

2

20Y-01-K2160

BRACKET

3

20Y-01-K2250

RING

4

20Y-01-K2121

PRESSURE SENSOR

5

20Y-01-K2111

SENSOR

6

20Y-01-K2060

MOUNT

7

20Y-01-K1950

FLANGE

8

20Y-01-K1961

TUBE

|8

20Y-01-K1960

TUBE

9

20Y-01-K1970

CLAMP

11

20Y-01-K2071

PLATE

|11

20Y-01-K2070

PLATE

12

01224-40620

SCREW

13

01643-30623

WASHER

14

01580-10605

NUT

15

01435-01030

BOLT

16

20Y-01-K2081

BRACKET

|16

20Y-01-K2080

BRACKET

17

01435-01030

BOLT

18

01435-01035

BOLT

19

01643-31032

WASHER

20

01580-11008

NUT

21

20Y-01-K2091

BRACKET

|21

20Y-01-K2090

BRACKET

22

01435-01030

BOLT

23

01435-01035

BOLT

24

01643-31032

WASHER

25

01580-11008

NUT

26

6754-11-5420

BRACKET

27

01435-01025

BOLT

28

01435-01035

BOLT

29

01643-31032

WASHER

30

01580-01008

NUT

31

20Y-01-K2190

TUBE

32

07260-20950

HOSE

33

07285-00155

CLAMP

34

20Y-01-K2260

FILTER BAG
