Запчасти Komatsu PC230NHD-8K РУКОЯТЬ АВТОМАТИЧ. СМАЗ. ЧАСТИ (.9M РУКОЯТЬ) (№K-) G АВТОМАТИЧ. СМАЗ. СИСТЕМА

|1

20Y-62-K8730

BLOCK ASSEMBLY

1

20Y-62-K7490

BLOCK

2

20Y-62-K8290

HOSE

3

20Y-62-K8270

HOSE

4

20Y-62-K8280

HOSE

5

01252-70635

BOLT

6

20Y-62-K7560

ELBOW

7

20Y-62-K7410

TUBE

8

20Y-62-K7420

TUBE

9

20Y-62-K7680

FITTING

10

20Y-62-K7540

FITTING

11

20Y-62-K7330

BRACKET

12

07283-33450

CLIP

13

07283-53444

SEAT

14

01643-31032

WASHER

15

01597-01009

NUT

16

04435-51210

CLIP

17

01010-81020

BOLT

18

01643-31032

WASHER

19

20Y-62-K7340

BRACKET

20

20J-70-12280

CLAMP

21

01010-81016

BOLT

22

01643-31032

WASHER

23

20Y-62-K7610

CLAMP

24

20Y-62-K7620

PLATE

25

20Y-62-K7570

BOLT

26

20Y-62-K7430

TUBE

27

20Y-62-K7440

TUBE

28

20Y-70-K5360

BOLT

29

20Y-62-K7320

BRACKET

30

01010-81225

BOLT

31

01643-31232

WASHER

32

20Y-62-K9420

WASHER

33

20Y-62-K8260

HOSE

34

20Y-62-K8810

HOSE

35

20Y-62-K8320

HOSE

36

08034-20414

BAND

37

01010-81240

BOLT

38

01643-31232

WASHER
