Запчасти Komatsu PC230NHD-8K РУКОЯТЬ АВТОМАТИЧ. СМАЗ. ЧАСТИ (.M РУКОЯТЬ) (№K-) G АВТОМАТИЧ. СМАЗ. СИСТЕМА

|1

20Y-62-K8721

BLOCK ASSEMBLY

1

20Y-62-K7490

BLOCK

2

20Y-62-K8481

HOSE

3

20Y-62-K8191

HOSE

4

20Y-62-K8211

HOSE

5

01252-70635

BOLT

6

20Y-62-K7560

ELBOW

7

20Y-62-K7990

TUBE

8

20Y-62-K7980

TUBE

9

20Y-62-K7680

FITTING

10

20Y-62-K7540

FITTING

11

20Y-62-K5980

BRACKET

12

07283-33450

CLIP

13

07283-53444

SEAT

14

01643-31032

WASHER

15

01597-01009

NUT

16

04435-51210

CLIP

17

04434-51510

CLIP

18

01010-81020

BOLT

19

01643-31032

WASHER

20

20Y-62-K7340

BRACKET

21

20J-70-12280

CLAMP

22

01010-81016

BOLT

23

01643-31032

WASHER

24

20Y-62-K7610

CLAMP

25

20Y-62-K7620

PLATE

26

20Y-62-K7570

BOLT

27

20Y-62-K8120

TUBE

28

20Y-62-K8110

TUBE

29

20Y-70-K5360

BOLT

30

20Y-62-K7320

BRACKET

31

01010-81225

BOLT

32

01643-31232

WASHER

33

20Y-62-K9420

WASHER

34

20Y-62-K8220

HOSE

35

20Y-62-K8180

HOSE

36

20Y-62-K8350

HOSE

37

08034-20414

BAND

38

01010-81240

BOLT

39

01643-31232

WASHER
