Запчасти Komatsu PC230NHD-8K КЛАПАН ПЕРЕГРУЗКИ (ДЛЯ ЦИЛИНДРА РУКОЯТИ) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

702-21-18151

PILOT VALVE

|1

702-21-08381

PILOT VALVE

|1

702-21-08380

PILOT VALVE

1

BODY, VALVE

2

SPOOL

3

702-21-38510

CASE

4

702-21-38420

RETAINER, 2.0MM

|4

702-21-38550

RETAINER, 1.7MM

|4

702-21-38560

RETAINER, 2.3MM

5

702-21-38741

PLATE

6

702-21-38440

SPRING

7

702-21-39740

SPRING

|7

702-21-38540

SPRING

8

702-21-38460

O-RING

9

702-21-38470

O-RING

10

702-21-38480

PLUG

11

01252-30825

BOLT

12

01252-30835

BOLT

13

01252-60625

BOLT

14

01641-20608

WASHER

15

07000-12021

O-RING

16

702-21-39690

VALVE

16

709-74-92810

VALVE

17

709-75-92220

SPRING

18

700-93-11320

O-RING

19

700-93-11330

RING, BACK-UP

20

723-40-91500

VALVE ASSEMBLY, RELIEF

21

700-80-64220

RING

22

700-22-11410

O-RING

23

709-25-11390

O-RING
