Запчасти Komatsu PC230NHD-8K СТРЕЛА ADJUST ЦИЛИНДР (ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XP460

CYLINDER GROUP, (FINAL COATING)

|1

707-01-0K540

CYLINDER ASSEMBLY

1

707-13-12620

CYLINDER

2

707-76-10290

BUSHING

3

07145-00100

SEAL, DUST (KIT)

4

07020-00000

FITTING, GREASE

5

721-58-10160

ROD

6

707-76-10290

BUSHING

7

07145-00100

SEAL, DUST (KIT)

8

07020-00000

FITTING, GREASE

9

707-27-16950

HEAD

10

176-63-56170

SEAL, DUST (KIT)

11

07179-13114

RING, SNAP

12

707-52-90780

BUSHING

13

707-75-10160

RING, SNAP

14

707-51-10030

PACKING, ROD (KIT)

15

707-51-10650

RING, BUFFER (KIT)

16

707-35-91640

RING, BACK-UP (KIT)

17

07000-15150

O-RING (KIT)

18

01010-82085

BOLT

19

707-88-75310

WASHER

20

707-36-16580

PISTON

21

01310-01216

SCREW

22

707-44-16150

RING, PISTON (KIT)

23

707-39-16120

RING, WEAR (KIT)

24

707-44-16910

RING

25

07001-05100

RING, BACK-UP (KIT)

26

07000-15100

O-RING (KIT)

27

707-86-12570

TUBE

28

07372-21060

BOLT

29

01643-51032

WASHER

30

07000-13035

O-RING (KIT)

31

707-88-25390

BRACKET

32

07372-21240

BOLT

33

01643-31232

WASHER

34

707-88-10150

CLAMP

35

01010-81245

BOLT

36

01643-51232

WASHER

37

707-88-33040

CAP

38

07371-31049

FLANGE, SPLIT

39

07372-21035

BOLT

40

01643-51032

WASHER

|K

707-99-66350

SERVICE KIT
