Запчасти Komatsu PC230NHD-8K СТРЕЛА ADJUST ЦИЛИНДР (ДЛЯ 2-СЕКЦИОНН. СТРЕЛЫ) (ПРАВ.) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XP450

CYLINDER ASSEMBLY, R.H.

|1

707-01-0K520

CYLINDER ASSEMBLY

1

707-13-12610

CYLINDER

2

707-76-70651

BUSHING

3

07145-00070

SEAL, DUST (KIT)

4

707-58-85430

ROD, PISTON

5

707-76-80431

BUSHING

6

07145-00080

SEAL, DUST (KIT)

7

707-27-12650

HEAD, CYLINDER

8

07179-13099

RING, SNAP

9

707-56-85510

SEAL, DUST (KIT)

10

707-52-90610

BUSHING

11

707-75-85110

RING, SNAP

12

707-51-85030

PACKING, ROD (KIT)

13

07000-15110

O-RING (KIT)

14

707-35-91220

RING, BACK-UP (KIT)

15

707-51-85650

RING, BUFFER (KIT)

16

01010-81670

BOLT

17

01643-51645

WASHER

18

707-36-12851

PISTON

19

707-44-12150

RING, PISTON (KIT)

20

707-39-12140

RING, WEAR (KIT)

21

707-44-12911

RING

22

707-71-70800

PLUNGER

23

07000-15075

O-RING (KIT)

24

707-35-90930

RING, BACK-UP (KIT)

25

01310-01216

SCREW

26

707-71-34660

COLLAR

27

707-35-91220

RING, BACK-UP (KIT)

28

07000-15110

O-RING (KIT)

29

707-86-68150

TUBE, R.H.

30

07372-21060

BOLT

31

01643-51032

WASHER

32

07372-21045

BOLT

33

01643-51032

WASHER

34

07000-13030

O-RING (KIT)

35

707-88-28020

BRACKET, R.H.

36

707-88-21620

BAND

37

07372-21035

BOLT

38

01643-51032

WASHER

39

07283-32738

CLIP

40

01597-01009

NUT

41

01643-31032

WASHER

|42

707-79-90060

VALVE ASSEMBLY

42

22U-62-27350

TUBE

43

07000-13030

O-RING

44

07372-21035

BOLT

45

01643-51032

WASHER

46

702-21-08330

PILOT VALVE

47

07000-13030

O-RING

48

07372-21060

BOLT

49

01643-51032

WASHER

50

07372-21050

BOLT

51

01643-51032

WASHER

52

707-88-33030

HEAD

53

07371-30640

FLANGE, SPLIT

54

07372-21035

BOLT

55

01643-51032

WASHER

56

07283-32738

CLIP

57

01597-01009

NUT

58

01643-31032

WASHER

|K

707-99-46390

SERVICE KIT
