Запчасти Komatsu PC230NHD-8K РУКОЯТЬ (.M) (№K-) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

20Y-944-K476

ARM

1

20Y-70-K4532

ARM

2

20Y-970-3570

BRACKET (WELDED)

3

20Y-970-7A10

PLATE (WELDED)

4

20Y-970-7A20

PLATE, L.H. (WELDED)

|4

20Y-970-7A30

PLATE, R.H. (WELDED)

5

20J-70-12180

SEAT (WELDED)

6

206-62-K2740

BRACKET (WELDED)

7

20Y-62-K7290

SEAT (WELDED)

8

20Y-70-32E50

SEAT (WELDED)

9

20Y-70-31272

BUSHING

10

20Y-70-32410

BUSHING

11

205-70-73180

BUSHING

12

07145-00090

SEAL

13

20Y-70-23220

SEAL

14

20Y-70-23230

SEAL

15

20Y-70-31160

PIN

16

20Y-62-K7651

PLATE

17

01010-81240

BOLT

18

01643-31232

WASHER

19

20Y-70-31431

SPACER, 1.0MM

20

205-70-71190

PIN

21

205-70-66580

PLATE

22

01010-81230

BOLT

23

01643-31232

WASHER

24

21K-70-71630

SPACER, 1.0MM

|24

20Y-70-31381

SPACER, 1.0MM

25

21K-70-71640

SPACER, 2.0MM

|25

20Y-70-31391

SPACER, 2.0MM

26

707-01-XR140

CYLINDER GROUP

|26

707-01-XJ150

CYLINDER GROUP
