Запчасти Komatsu PC230NHD-8K КОНЕЧНАЯ ПЕРЕДАЧА (NHD) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|1

206-27-00423

FINAL DRIVE ASSEMBLY

|1

206-27-00422

FINAL DRIVE ASSEMBLY

1

708-8F-00192

MOTOR ASSEMBLY

|2

150-27-00410

FLOATING SEAL ASSEMBLY

2

20Y-27-22310

RING

3

14S-27-00110

O-RING

4

22U-27-21182

HUB

5

20Y-27-22230

BEARING

6

22U-27-21220

O-RING

7

20Y-27-22261

LOCK

8

20Y-27-22270

LOCK

9

01010-81020

BOLT

10

22U-27-21171

CARRIER

|10

22U-27-21170

CARRIER

11

22U-27-21140

GEAR

12

20Y-27-22220

BEARING

13

20Y-27-21250

WASHER

14

22U-27-21230

PIN

15

20Y-27-21290

PIN

16

20Y-27-13310

WASHER

17

22U-27-21130

GEAR

18

22U-27-21210

THRUST WASHER

19

22U-27-21153

GEAR

20

22U-27-21161

CARRIER

21

22U-27-21120

GEAR

22

20Y-27-22210

BEARING

23

22U-27-21240

THRUST WASHER

24

20Y-27-21220

PIN

25

20Y-27-21280

PIN

26

22U-27-21110

SHAFT

27

20Y-27-21310

WASHER

28

22U-27-21192

COVER

29

20Y-27-22250

BUTTON

30

20Y-27-13281

BOLT

31

01643-31645

WASHER

32

07049-01012

PLUG

33

07044-12412

PLUG

34

07002-02434

O-RING

35

20Y-27-11582

SPROCKET

36

20Y-27-11561

BOLT

37

01010-B1660

BOLT

38

01643-31645

WASHER

39

20Y-30-21191

COVER

40

01010-81230

BOLT

41

01643-31232

WASHER
