Запчасти Komatsu PC230NHD-7K ЦИЛИНДР КОВША (ДЛЯ .9M РУКОЯТЬ) (№K8-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XY452

CYLINDER GROUP

|1

707-01-XA992

CYLINDER ASS'Y

1

707-13-11561

CYLINDER

2

707-76-70651

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-58-80651

ROD,PISTON

5

707-76-70120

BUSHING

6

20Y-70-23220

SEAL,DUST (KIT)

7

707-27-11870

HEAD,CYLINDER

8

07179-13094

RING,SNAP

9

195-63-92190

SEAL,DUST (KIT)

10

707-52-90560

BUSHING

11

707-51-80030

PACKING,ROD (KIT)

12

07000-15105

O-RING (KIT)

13

707-35-91150

RING,BACK-UP (KIT)

14

707-51-80640

RING,BUFFER (KIT)

15

707-75-80040

SEAL

16

01010-81670

BOLT

17

01643-51645

WASHER

18

707-36-11851

PISTON

19

707-44-11280

RING,PISTON (KIT)

20

707-39-11530

RING,WEAR (KIT)

21

707-44-11920

RING

22

707-35-90360

RING (KIT)

23

07000-15070

O-RING (KIT)

24

01310-01216

SCREW

25

07020-00000

FITTING,GREASE

26

07020-00000

FITTING,GREASE

27

707-86-66281

TUBE

28

07375-21060

BOLT

29

07375-21045

BOLT

30

07000-13030

O-RING (KIT)

31

707-88-22570

BRACKET

32

707-88-21271

BAND

33

07375-21035

BOLT

34

07283-32738

CLIP

35

01597-01009

NUT

36

01643-31032

WASHER

|K

707-99-45230

SERVICE KIT
