Запчасти Komatsu PC230LC-7-BA ЦИЛИНДР КОВША (СПЕЦ-Я ДЛЯ РАЗРУШ. ЗДАНИЙ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XZ950

CYLINDER GROUP,(FINAL COATING)

|1

707-01-0A420

CYLINDER ASS'Y

1

707-13-14570

CYLINDER

2

707-76-80470

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-10710

ROD,PISTON

5

707-76-80480

BUSHING

6

20Y-70-23230

SEAL,DUST (KIT)

7

707-27-14930

HEAD,CYLINDER

8

07179-13114

RING,SNAP

9

176-63-56170

SEAL,DUST (KIT)

10

707-52-90780

BUSHING

11

707-51-10030

PACKING,ROD (KIT)

12

07000-15130

O-RING (KIT)

13

707-35-91420

RING,BACK-UP (KIT)

14

707-51-10640

RING,BUFFER (KIT)

15

01010-81875

BOLT

16

707-41-11840

WASHER

17

707-36-14650

PISTON

18

707-44-14180

RING,PISTON (KIT)

19

707-39-14110

RING,WEAR (KIT)

20

707-44-14910

RING

21

07001-05090

RING,BACK-UP (KIT)

22

07000-15090

O-RING (KIT)

23

01310-01216

SCREW

24

07020-00000

FITTING,GREASE

25

07020-00900

FITTING,GREASE

26

707-86-66390

TUBE

27

01435-01055

BOLT

28

01435-01040

BOLT

29

07000-13030

O-RING (KIT)

30

707-88-22680

BRACKET

31

707-88-21361

BAND

32

01435-01030

BOLT

33

07283-22738

CLIP

34

01599-01011

NUT

35

01643-31032

WASHER

36

707-88-33030

HEAD

37

07371-30640

FLANGE,SPLIT

38

07372-21035

BOLT

39

01643-51032

WASHER

|K

707-99-58060

SERVICE KIT
