Запчасти Komatsu PC230LC-7-BA МЕХАНИЗМ ПОВОРОТА(№-) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

206-26-73110

CASE

2

206-26-73150

BEARING

3

206-26-73160

BEARING

4

206-26-73130

SHAFT

5

206-26-73140

SPACER

6

07000-15100

O-RING

7

20Y-26-22420

SEAL

8

206-26-73120

COVER

9

01010-81040

BOLT

10

01643-31032

WASHER

11

07000-15310

O-RING

12

206-26-71480

CARRIER

13

206-26-71440

GEAR

14

22U-26-21320

BEARING

15

206-26-71520

THRUST WASHER

16

206-26-71510

PIN

17

20Y-26-21330

PIN

18

20Y-26-21240

PLATE

19

112-32-11211

BOLT¤ SHOE

20

206-26-71452

GEAR

21

20K-22-11190

O-RING

22

01010-81440

BOLT

23

01643-31445

WASHER

24

206-26-71430

GEAR

25

04260-01270

BALL

26

206-26-71470

CARRIER

27

206-26-71420

GEAR

28

20Y-27-22210

BEARING

29

22U-26-21230

WASHER

30

206-26-71210

PIN

31

04064-03515

RING

32

206-26-71350

HOLDER

33

206-26-71410

GEAR

34

206-26-71340

PLATE

35

195-03-13241

VALVE

36

07270-21560

TUBE

37

07281-00197

CLAMP

38

01010-81035

BOLT

39

01643-51032

WASHER

40

22U-26-21280

RING

41

07043-00312

PLUG

42

706-7G-01040

MOTOR ASS'Y

43

20Y-26-31410

TUBE

44

20Y-26-31420

FILLER

45

20Y-26-31430

GAUGE

46

20Y-26-31441

BRACKET

47

22U-26-21460

CAP

48

07238-10630

CONNECTOR

49

07283-32738

CLIP

50

04434-51710

CLIP

51

01597-01009

NUT

52

01643-31032

WASHER

53

01010-81030

BOLT

54

01643-31032

WASHER

55

01010-81025

BOLT

56

01643-31032

WASHER

57

07000-15250

O-RING

58

01010-82070

BOLT

59

01643-32060

WASHER
