Запчасти Komatsu PC230LC-7-BA МЕХАНИЗМ ПОВОРОТА(№-9) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

206-26-71490

CASE

2

20Y-26-22330

BEARING

3

206-26-71240

BEARING

4

206-26-71460

SHAFT

5

07012-00115

SEAL

6

206-26-71310

SPACER

7

07000-15310

O-RING

8

206-26-71480

CARRIER

9

206-26-71440

GEAR

10

22U-26-21320

BEARING

11

206-26-71520

THRUST WASHER

12

206-26-71510

PIN

13

20Y-26-21330

PIN

14

20Y-26-21240

PLATE

15

112-32-11211

BOLT¤ SHOE

16

206-26-71452

GEAR

17

20K-22-11190

O-RING

18

01010-81440

BOLT

19

01643-31445

WASHER

20

206-26-71430

GEAR

21

04260-01270

BALL

22

206-26-71470

CARRIER

23

206-26-71420

GEAR

24

20Y-27-22210

BEARING

25

22U-26-21230

WASHER

26

206-26-71210

PIN

27

04064-03515

RING

28

206-26-71350

HOLDER

29

206-26-71410

GEAR

30

206-26-71340

PLATE

31

195-03-13241

VALVE

32

07270-21560

TUBE

33

07281-00197

CLAMP

34

01010-81035

BOLT

35

01643-51032

WASHER

36

22U-26-21280

RING

37

07043-00312

PLUG

38

706-7G-01040

MOTOR ASS'Y

39

20Y-26-31410

TUBE

40

20Y-26-31420

FILLER

41

20Y-26-31430

GAUGE

42

20Y-26-31441

BRACKET

43

22U-26-21460

CAP

44

07238-10630

CONNECTOR

45

07283-32738

CLIP

46

04434-51710

CLIP

47

01597-01009

NUT

48

01643-31032

WASHER

49

01010-81030

BOLT

50

01643-31032

WASHER

51

01010-81025

BOLT

52

01643-31032

WASHER

53

22U-26-21370

HOSE

54

22U-26-21380

PLATE

55

22U-26-21390

CLAMP

56

205-70-51390

NIPPLE

57

07020-00000

FITTING

58

04434-51210

CLIP

59

130-802-5110

CLIP

60

01010-81020

BOLT

61

01643-31032

WASHER

62

07000-15250

O-RING

63

01010-82070

BOLT

64

01643-32060

WASHER
