Запчасти Komatsu PC230LC-6 ТАБЛИЧКИ (ЯПОН.)(№9-8) МАРКИРОВКА

1

09685-00001

PLATE¤ OPERATING,SAFETY LOCK LEVER

2

205-00-73360

PLATE¤ OPERATING,HYDRAULIC OIL LEVEL

3

09690-M0063

PLATE¤ MARK,KOMATSU

4

09690-B0315

PLATE¤ MARK,KOMATSU

5

20Y-00-22780

PLATE¤ MARK,ONE POINT DECAL

6

206-00-61150

PLATE¤ MARK,PC230LC

7

14X-98-11141

PLATE¤ SAFETY,RADIATOR CAP

8

09652-01121

PLATE¤ CAUTION,FUEL INLET

9

203-00-61160

PLATE¤ SAFETY,HYDRAULIC OIL INLET

10

20Y-00-21121

PLATE¤ MARK,KEEP OFF SWING AREA

11

20Y-00-21130

PLATE,OVERRIDE SWITCH

12

20Y-00-21191

PLATE,FUSE

13

203-00-61210

PLATE¤ CAUTION,HAZARDOUS VOLTAGE HAZARD

14

14X-98-11280

PLATE¤ SAFETY,OPERATION AND MAINTENANCE

15

203-00-61180

PLATE¤ CAUTION,WINDOW LOCK

16

203-00-61170

PLATE¤ CAUTION,SAFETY LOCK LEVER

17

203-916-5730

PLATE¤ OPERATING,ISO PATTERN

18

20Y-00-21360

PLATE,HOOD

19

20Y-00-21151

PLATE,LUBRICATION CHART

20

203-00-61191

PLATE¤ CAUTION,BEFORE OPERATION

21

14X-98-11161

PLATE¤ SAFETY,TRACK ADJUSTMENT

22

14X-98-11380

PLATE¤ CAUTION,ACCUMULATOR

23

20Y-00-21161

PLATE¤ AVANCE DECAL

24

09601-00835

PLATE¤ NAME,MACHINE MODEL

25

04418-13060

SCREW

26

09963-00100

TAG,DO NOT OPERATE

27

206-00-61183

PLATE,SPECIFICATION

28

203-00-51170

SEAT

29

154-54-23260

SEAT

30

20Y-00-22890

SHEET

31

20Y-54-36290

PLATE

|31

20Y-54-36250

PLATE

32

20Y-00-22990

PLATE¤ MARK,KOMATSU

|32

09690-B0315

PLATE¤ MARK,KOMATSU
