Запчасти Komatsu PC230LC-6 КЛАПАН PPC(ДЛЯ ХОДА)(№9-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$3

702-16-01542

PILOT VALVE

|$4

702-16-01541

PILOT VALVE

|$5

702-16-01540

PILOT VALVE

1

BODY,VALVE

2

VALVE

3

702-16-51140

SHIM, 0.30MM

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-51270

SEAL

9

07000-12020

O-RING

10

702-16-54170

COLLAR

11

702-16-54311

CASE

11

702-16-54310

CASE

12

LEVER

13

SHAFT

14

PLATE

14

PLATE

15

01010-80855

BOLT

16

01643-30823

WASHER

17

01010-80816

BOLT

18

702-16-54331

WASHER, 1.60MM

18

702-16-54341

WASHER, 1.30MM

18

702-16-54351

WASHER, 1.00MM

19

04025-00432

PIN,SPRING

20

702-16-54430

BUSHING

21

702-16-54280

SEAL,DUST

22

702-16-54506

DAMPER ASS'Y

22

702-16-54505

DAMPER ASS'Y

22

702-16-54503

DAMPER ASS'Y

23

01252-60525

BOLT

24

702-16-54511

PLATE

25

04025-00420

PIN,SPRING

26

LEVER

27

01224-40612

SCREW

28

PLUG

29

PLUG

30

07040-11209

PLUG

31

07002-11223

O-RING

32

700-84-11730

BALL

33

702-16-55940

PLUG

34

702-16-55950

SEAT

35

04022-04016

PIN,DOWEL

36

04022-04010

PIN,DOWEL
