Запчасти Komatsu PC228UU-1-TN ОСНОВН. КЛАПАН (-АКТУАТОР) (/) (ТУННЕЛЬН. СПЕЦ-Я./ДЛЯ MONO-СТРЕЛА)(№-7) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-48-14104

CONTROL VALVE

|1

723-48-14103

CONTROL VALVE

|1

723-48-14102

CONTROL VALVE

|1

723-48-14101

CONTROL VALVE

|1

723-46-00640

COVER ASS'Y

|1

723-46-00610

COVER ASS'Y

1

COVER,A

|1

COVER,A

2

PLUG

|2

PLUG

2A

PLUG

|3

723-46-00620

COVER ASS'Y

3

COVER,B

4

PLUG

5

PLUG

6

723-46-15150

VALVE

7

723-46-14150

SPRING

8

723-46-15180

PLUG

|8

723-46-15180

PLUG

9

07002-11823

O-RING

|9

07002-11823

O-RING

9A

708-8H-11530

PLUG

9B

07002-11423

O-RING

|10

723-46-15100

PLUG ASS'Y

10

PLUG

11

SCREW

12

07002-11423

O-RING

13

07000-11007

O-RING

14

07001-01007

RING,BACK-UP

15

723-46-15190

VALVE

16

723-46-14140

SPRING

17

708-8E-16160

PLUG

18

07002-11023

O-RING

19

709-74-91860

PLUG

20

07002-12434

O-RING

21

01010-61490

BOLT

22

01643-31445

WASHER

23

723-46-15220

BOLT

|24

723-46-15200

PLUG ASS'Y

24

723-46-15270

PLUG

25

07000-03032

O-RING

26

07002-13034

O-RING

27

700-80-61430

RING

28

700-80-61260

O-RING

29

07000-12021

O-RING

30

07001-02021

RING,BACK-UP
