Запчасти Komatsu PC228UU-1-TN ЦИЛИНДР СТРЕЛЫ(№-7) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

22U-63-X2202

CYLINDER GROUP,L.H.

G-1

22U-63-X2201

CYLINDER GROUP,L.H.

G-2

22U-63-X2212

CYLINDER GROUP,R.H.

G-2

22U-63-X2211

CYLINDER GROUP,R.H.

|1

22U-63-02202

CYLINDER ASS'Y

|1

22U-63-02201

CYLINDER ASS'Y

1

22U-63-52341

CYLINDER

2

205-70-71360

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

22U-63-52321

ROD,PISTON

5

707-76-80010

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-12921

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90610

BUSHING

11

707-51-85030

PACKING,ROD (KIT)

12

07000-15110

O-RING (KIT)

13

707-35-91220

RING,BACK-UP (KIT)

14

707-51-85630

RING,BUFFER (KIT)

15

707-88-83632

BRACKET

|15

707-88-83631

BRACKET

16

01010-81670

BOLT

17

01643-51645

WASHER

18

707-36-12071

PISTON

19

707-44-12180

RING,PISTON (KIT)

20

707-39-12110

RING,WEAR (KIT)

21

707-44-12911

RING

22

07000-15075

O-RING (KIT)

23

707-35-90930

RING,BACK-UP (KIT)

24

01310-01216

SCREW

25

22U-63-52371

TUBE,L.H.

|25

22U-63-52471

TUBE,R.H.

26

22U-63-52380

TUBE,L.H.

|26

22U-63-52480

TUBE,R.H.

27

01435-01055

BOLT

28

01435-01040

BOLT

29

07000-13030

O-RING (KIT)

30

22U-63-52391

BRACKET,L.H.

|30

22U-63-52491

BRACKET,R.H.

31

707-88-96530

BAND

32

01010-81035

BOLT

33

01643-51032

WASHER

34

22U-62-99963

PLATE,L.H.

|34

22U-62-99964

PLATE,R.H.

35

07283-22738

CLIP

36

01599-01011

NUT

37

01643-31032

WASHER

|38

707-98-46220

SERVICE KIT
