Запчасти Komatsu PC228UU-1-TN КАБИНА(№-7) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

22U-54-00010

OPERATOR'S CAB ASS'Y

1

22U-54-14110

CAB ASS'Y

|1

21J-54-16160

CAB ASS'Y,GUARD

2

22U-54-14620

PACKING

3

21J-54-14751

WINDOW,UPPER/L.H

4

20U-54-24971

DAM

5

21J-54-14761

WINDOW,LOWER/L.H

6

20U-54-24981

DAM

7

21J-54-14860

LINING

8

21J-54-14871

LINING,L.H

9

21J-54-14882

LINING,R.H

10

20U-54-25170

SEAL

11

22U-54-14510

GLASS,R.H

12

21J-54-14720

DAM

13

21J-54-14733

CLEAR PLATE,ROOF

|13

21J-54-14732

CLEAR PLATE,ROOF

14

21J-54-14662

SEAL,ROOF

15

20T-54-74780

INSULATOR

|15

205-54-51720

RETAINER

16

20T-54-74880

GROMMET

|16

205-54-51730

PACKING

16A

01643-71232

WASHER

17

01224-40610

SCREW

18

22U-54-14550

BRACKET

19

01023-20510

SCREW

20

22U-54-14560

PLATE

21

01023-10616

SCREW

22

01584-30605

NUT

23

21J-54-14770

GLASS

24

205-54-51720

RETAINER

25

205-54-51730

PACKING

26

01224-40610

SCREW

27

21J-54-14740

SEAL

28

22X-54-19260

LOCK

29

01224-40510

SCREW

30

01584-30504

NUT
