Запчасти Komatsu PC228UU-1-TN ТОПЛИВН. БАК.(№-7) ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

22U-04-11112

TANK

2

21W-04-21121

FLANGE

3

01220-40630

SCREW

4

01602-20619

WASHER

5

07000-02015

O-RING

6

20U-04-21430

FLANGE

7

07700-50345

VALVE

8

01220-40620

SCREW

9

01602-20619

WASHER

10

07000-02015

O-RING

11

201-968-1470

ELBOW

12

7861-92-5820

SENSOR,FUEL

13

01252-40612

BOLT

14

01602-20619

WASHER

15

07000-03048

O-RING

16

22U-04-11211

BRACKET

17

22U-04-11221

BRACKET

18

22U-04-11231

BRACKET

19

22U-04-11242

BRACKET

20

01010-81230

BOLT

21

01010-81250

BOLT

22

01643-31232

WASHER

23

22U-04-11201

BAND ASS'Y

24

22U-04-11301

BAND ASS'Y

25

22U-04-11401

BAND ASS'Y

26

22U-04-11500

BAND ASS'Y

27

22U-04-11280

PIN

28

04052-11038

PIN

29

01580-11210

NUT

30

01643-31232

WASHER
