Запчасти Komatsu PC228UU-1-TN ТОПЛИВН. БАК.(№-) ТОПЛИВН. БАК. AND КОМПОНЕНТЫ

1

22U-04-11111

TANK

2

21W-04-21121

FLANGE

3

01220-40630

SCREW

4

01602-20619

WASHER

5

07000-02015

O-RING

6

21Y-04-11130

FLANGE

7

20Y-04-11130

VALVE

8

01220-40620

SCREW

9

01602-20619

WASHER

10

07000-02015

O-RING

11

20B-04-21110

NIPPLE

12

20G-68-12930

ELBOW

13

21Y-04-11380

FLANGE ASS'Y

14

01220-40616

SCREW

15

01602-20619

WASHER

16

07000-02015

O-RING

17

7861-92-5820

SENSOR,FUEL

18

01252-40612

BOLT

19

01602-20619

WASHER

20

07000-03048

O-RING

21

22U-04-11211

BRACKET

22

22U-04-11220

BRACKET

23

22U-04-11230

BRACKET

24

22U-04-11241

BRACKET

25

01010-51230

BOLT

26

01643-31232

WASHER

27

22U-04-11200

BAND ASS'Y

28

22U-04-11300

BAND ASS'Y

29

22U-04-11400

BAND ASS'Y

30

22U-04-11500

BAND ASS'Y

31

22U-04-11280

PIN

32

04052-11038

PIN

33

01580-11210

NUT

34

01643-31232

WASHER
