Запчасти Komatsu PC228UU-1-TN ПЕРЕДН. КРЫШКА(COVER) (/) ( АКТУАТОР) (ДЛЯ MONO-СТРЕЛА)(№9-7) ЧАСТИ КОРПУСА

|1

22U-54-12382

COVER

1

COVER

2

22U-54-11161

LOCK

3

22U-54-12762

SHEET

4

22U-54-12771

SHEET

5

22U-54-12870

SEAL

6

01010-81230

BOLT

7

175-54-34170

WASHER

8

22U-54-11331

CAP

9

01010-81230

BOLT

10

21N-30-11340

COLLAR

11

01643-31232

WASHER

12

22U-54-12490

COVER

|13

22U-54-12392

COVER

13

COVER

14

22U-54-11911

SEAL

15

22U-54-11991

SEAL

16

22U-54-12781

SHEET

17

22U-54-12790

SHEET

18

20Y-54-27502

LOCK ASS'Y

19

01010-81025

BOLT

20

01643-31032

WASHER

21

22U-54-11182

ROD

22

01643-31032

WASHER

23

04050-13020

PIN

24

22U-54-12250

BRACKET

25

01010-81230

BOLT

26

01643-31232

WASHER

27

01010-81230

BOLT

28

01643-31232

WASHER

29

175-54-34170

WASHER

30

22U-54-11390

CAP

31

22U-54-12170

BRACKET

32

01010-81230

BOLT

33

01643-31232

WASHER

|34

22U-54-12910

COVER

34

COVER

35

22U-54-11940

SEAL

36

22U-54-11950

SEAL

37

22U-54-12810

SHEET

38

22U-54-12821

SHEET

39

08037-03614

GROMMET

40

01010-81230

BOLT

41

01643-31232

WASHER

42

175-54-34170

WASHER

43

22U-54-12270

BRACKET

44

01010-81225

BOLT

45

01643-31232

WASHER
