Запчасти Komatsu PC228UU-1 МОТОР ПОВОРОТА (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-75-01181

SWING MOTOR ASS'Y

|1

706-75-03040

MOTOR SUB ASS'Y

1

706-75-42662

SHAFT

2

706-75-42880

BEARING

3

706-76-40890

BEARING

4

706-7E-11260

SPRING

5

706-7E-11270

SEAT

6

706-75-05010

SPACER KIT

|6

SPACER¤ 5.0MM

|6

SPACER¤ 5.4MM

|6

SPACER¤ 5.8MM

7

04064-04518

RING,SNAP

8

706-7E-11280

SEAL,OIL

9

706-75-42711

COVER

10

07000-02085

O-RING

11

04065-09030

RING,SNAP

12

706-75-41091

BLOCK,CYLINDER

13

706-75-42740

PLATE,VALVE

14

04020-00820

PIN

15

706-75-42180

SHAFT,CENTER

16

706-75-41130

RING,CENTER

17

706-75-41220

BALL,CENTER

18

706-75-41110

SPRING

|19

706-75-05020

RETAINER KIT

19

RETAINER

20

SCREW

21

706-75-41163

PISTON SUB ASS'Y

22

706-75-92130

PLATE

23

706-75-92141

PLATE

24

706-75-92150

DISK

25

706-75-92180

PISTON,BRAKE

26

07000-15155

O-RING

27

07000-15175

O-RING

28

706-75-92170

SPRING
