Запчасти Komatsu PC228UU-1 МОТОР ПОВОРОТА (/)(№-7) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|1
706-75-01190
SWING MOTOR ASS'Y
|1
706-75-03340
MOTOR SUB ASS'Y
1
706-75-43110
CASE
|2
706-75-00150
HOUSING SUB ASS'Y
2
706-75-74910
HOUSING
3
706-86-51180
PLUG
4
706-75-40010
BEARING
5
706-75-42820
PIN,DOWEL
6
706-77-72170
PLUG
7
07002-12434
O-RING
8
708-8H-11530
PLUG
9
07002-11423
O-RING
|10
706-73-72710
VALVE SUB ASS'Y
10
706-73-72720
VALVE
11
706-73-72730
POPPET
12
706-73-72740
PLUG
13
706-73-72440
SPRING
14
706-73-72750
PLUG
15
07000-12020
O-RING
16
07001-02020
RING,BACK-UP
17
706-75-74540
VALVE
18
706-75-74550
SPRING
19
706-75-74850
PLUG
20
07002-13334
O-RING
21
565-14-22440
O-RING
22
01252-61445
BOLT
|1
706-75-01190
SWING MOTOR ASS'Y
|1
706-75-03340
MOTOR SUB ASS'Y
1
706-75-43110
CASE
|2
706-75-00150
HOUSING SUB ASS'Y
2
706-75-74910
HOUSING
3
706-86-51180
PLUG
4
706-75-40010
BEARING
5
706-75-42820
PIN,DOWEL
6
706-77-72170
PLUG
7
07002-12434
O-RING
8
708-8H-11530
PLUG
9
07002-11423
O-RING
|10
706-73-72710
VALVE SUB ASS'Y
10
706-73-72720
VALVE
11
706-73-72730
POPPET
12
706-73-72740
PLUG
13
706-73-72440
SPRING
14
706-73-72750
PLUG
15
07000-12020
O-RING
16
07001-02020
RING,BACK-UP
17
706-75-74540
VALVE
18
706-75-74550
SPRING
19
706-75-74850
PLUG
20
07002-13334
O-RING
21
565-14-22440
O-RING
22
01252-61445
BOLT
Выбрано товаров: 52
