Запчасти Komatsu PC228UU-1 ЦИЛИНДР КОВША(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

22U-63-X2131

CYLINDER GROUP

|1

205-63-03131

CYLINDER ASS'Y

1

205-63-71141

CYLINDER

2

707-76-70110

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

205-63-71121

ROD,PISTON

5

707-76-70120

BUSHING

6

21K-70-12180

SEAL,DUST (KIT)

7

707-27-11981

HEAD,CYLINDER

8

07179-13094

RING,SNAP

9

195-63-92190

SEAL,DUST (KIT)

10

707-52-90560

BUSHING

11

707-51-80030

PACKING,ROD (KIT)

12

07000-15105

O-RING (KIT)

13

707-35-91150

RING,BACK-UP (KIT)

14

707-51-80630

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-11661

PISTON

18

707-44-11280

RING,PISTON (KIT)

19

707-39-11510

RING,WEAR (KIT)

20

707-44-11920

RING

21

707-35-90360

RING (KIT)

22

07000-15070

O-RING (KIT)

23

01310-01216

SCREW

24

07020-00000

FITTING,GREASE

25

07020-00900

FITTING,GREASE

26

707-87-13950

ELBOW

27

07000-13030

O-RING (KIT)

28

01435-01090

BOLT

29

22U-63-72171

TUBE

30

22U-63-72181

TUBE

31

07000-13030

O-RING (KIT)

32

01435-01055

BOLT

33

01435-01040

BOLT

34

22U-63-72191

BRACKET

35

707-88-95350

BAND

36

01010-81035

BOLT

37

01643-51032

WASHER

38

07283-22738

CLIP

39

01599-01011

NUT

40

01643-31032

WASHER

|41

707-98-45260

SERVICE KIT
