Запчасти Komatsu PC228UU-1 ЦИЛИНДР РУКОЯТИ(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

22U-63-X2123

CYLINDER GROUP

G-1

22U-63-X2122

CYLINDER GROUP

G-1

22U-63-X2121

CYLINDER GROUP

|1

22U-63-02123

CYLINDER ASS'Y

|1

22U-63-02121

CYLINDER ASS'Y

1

22U-63-62142

CYLINDER

|1

22U-63-62141

CYLINDER

2

707-76-80010

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

22U-63-62120

ROD,PISTON

5

707-27-13961

HEAD,CYLINDER

6

07179-13109

RING,SNAP

7

707-56-95510

SEAL,DUST (KIT)

8

707-52-90720

BUSHING

9

707-51-95030

PACKING,ROD (KIT)

10

07000-15125

O-RING (KIT)

11

707-35-91370

RING,BACK-UP (KIT)

12

707-51-95630

RING,BUFFER (KIT)

13

01010-81875

BOLT

14

707-41-11840

WASHER

15

707-36-13731

PISTON

16

707-44-13280

RING,PISTON (KIT)

17

707-39-13510

RING,WEAR (KIT)

18

707-44-13920

RING

19

07000-15085

O-RING (KIT)

20

707-35-90960

RING,BACK-UP (KIT)

21

01310-01216

SCREW

22

707-71-60230

PLUNGER

23

07020-00900

FITTING,GREASE

24

04260-00635

BALL

25

707-71-91270

CAP

25A

707-83-13010

VALVE

25B

07750-01628

SPRING

25C

707-87-14070

PLUG

25D

07002-12034

O-RING (KIT)

26

22U-63-62172

TUBE

|26

22U-63-62171

TUBE

27

22U-63-62181

TUBE

|27

22U-63-62180

TUBE

28

01435-01055

BOLT

29

01435-01040

BOLT

30

07000-13030

O-RING (KIT)

31

01435-01055

BOLT

32

07000-13035

O-RING (KIT)

33

22U-63-62190

BRACKET

34

707-88-87260

BAND

35

01010-81240

BOLT

36

01643-51232

WASHER

37

07283-23442

CLIP

38

07283-22738

CLIP

39

01599-01011

NUT

40

01643-31032

WASHER

|41

707-99-57280

SERVICE KIT

|41

707-99-57260

SERVICE KIT
