Запчасти Komatsu PC228UU-1 ОХЛАЖД-Е (РАДИАТОР И ТРУБЫ)(№-7) СИСТЕМА ОХЛАЖДЕНИЯ

1

22U-03-11110

RADIATOR CORE A

2

20Y-03-22110

CAP

3

205-03-62660

PLUG

4

07000-01007

O-RING

5

363-03-11150

TUBE

6

20Y-03-11330

CLIP

7

22U-03-11121

OIL COOLER ASS'Y

8

20Y-03-11242

SEAL

9

01010-81225

BOLT

10

01643-31232

WASHER

11

22U-03-11140

NET

12

22U-03-11150

NET

13

20Y-03-11570

SEAL

14

01434-10616

BOLT¤ WING

15

01643-30823

WASHER

16

22U-03-11450

SEAL

17

22U-03-11132

SHROUD

18

01435-20816

BOLT

19

20Y-03-14110

SEAL

20

22U-979-1110

BRACKET

21

01010-81025

BOLT

22

01643-31032

WASHER

23

22U-979-1120

BRACKET

24

01010-81025

BOLT

25

01643-31032

WASHER

26

22U-03-11421

SHEET

27

22U-03-11431

SHEET

28

22U-03-11441

SHEET

29

22U-03-11460

SHEET

30

22U-03-11470

SHEET

31

22U-03-11221

HOSE

32

07289-00055

CLAMP

33

22U-03-11210

HOSE

34

07289-00055

CLAMP

35

07289-00070

CLAMP

36

208-62-38370

CLIP

37

01010-81040

BOLT

38

01643-31032

WASHER

39

6631-11-5630

SPACER
