Запчасти Komatsu PC228UU-1 ПЕРЕДН. КРЫШКА(COVER) (/)(№-7) ЧАСТИ КОРПУСА

|$4

22U-54-12382

COVER

1

COVER

2

22U-54-11161

LOCK

3

22U-54-11192

SEAL

4

22U-54-11341

SEAL

5

22U-54-11361

SEAL

6

22U-54-12762

SHEET

7

22U-54-12771

SHEET

8

22U-54-12870

SEAL

9

01010-81230

BOLT

10

175-54-34170

WASHER

11

22U-54-11331

CAP

12

01010-81230

BOLT

13

21N-30-11340

COLLAR

14

01643-31232

WASHER

15

22U-54-12490

COVER

|$21

22U-54-12392

COVER

16

COVER

17

22U-54-11911

SEAL

18

22U-54-11991

SEAL

19

22U-54-12781

SHEET

20

22U-54-12790

SHEET

21

20Y-54-27502

LOCK ASS'Y

22

01010-81025

BOLT

23

01643-31032

WASHER

24

22U-54-11182

ROD

25

01643-31032

WASHER

26

04050-13020

PIN

27

22U-54-12250

BRACKET

28

01010-81230

BOLT

29

01643-31232

WASHER

30

01010-81230

BOLT

31

01643-31232

WASHER

32

175-54-34170

WASHER

33

22U-54-11390

CAP

34

22U-54-12170

BRACKET

35

01010-81230

BOLT

36

01643-31232

WASHER

|$50

22U-54-12412

COVER

37

COVER

38

22U-54-11940

SEAL

39

22U-54-11950

SEAL

40

22U-54-12810

SHEET

41

22U-54-12821

SHEET

42

08037-03614

GROMMET

43

01010-81230

BOLT

44

01643-31232

WASHER

45

175-54-34170

WASHER

46

22U-54-12270

BRACKET

47

01010-81225

BOLT

48

01643-31232

WASHER
