Запчасти Komatsu PC228UU-1 МОТОР ПОВОРОТА (/)(№7-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$2

706-75-01170

MOTOR ASS'Y

|$3

706-75-01190

SWING MOTOR ASS'Y

|$5

706-75-03330

MOTOR SUB ASS'Y

|$6

706-75-03340

MOTOR SUB ASS'Y

1

706-75-43660

SHAFT,DRIVE

2

706-75-42880

BEARING

3

706-75-43810

SPACER

4

706-7E-11260

SPRING

5

706-7E-11270

SEAT

6

706-76-40890

BEARING

7

706-75-05040

SPACER KIT

7

SPACER, 3.1MM

7

SPACER, 3.4MM

7

SPACER, 3.7MM

8

04064-04518

RING,SNAP

9

706-7E-11280

SEAL

10

706-75-43720

SPACER

11

04065-06220

RING

12

706-75-43190

BLOCK,CYLINDER

13

706-75-43741

PLATE,VALVE

14

706-75-43750

PIN,DOWEL

15

706-75-43120

SHAFT,CENTER

16

706-75-43130

RING,CENTER

17

706-75-43140

SPRING

|$27

706-75-05020

RETAINER KIT

18

RETAINER

19

SCREW

20

706-75-43160

PISTON SUB ASS'Y

21

706-75-92130

PLATE

22

706-75-92340

PLATE

23

706-75-92350

DISK

24

706-75-92380

PISTON,BRAKE

25

706-75-92390

RING,BRAKE

26

07000-12145

O-RING

27

706-75-92310

O-RING

28

706-75-92360

SPRING
