Запчасти Komatsu PC228UU-1-MO ОСНОВН. КЛАПАН (-АКТУАТОР) (/) (ДЛЯ MONO-СТРЕЛА)(№-7) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-48-14104

CONTROL VALVE

|1

723-48-14103

CONTROL VALVE

|1

723-41-00400

BODY SUB ASS'Y

1

BLOCK,VALVE

2

SPOOL

3

723-46-15130

PLUG

4

07002-10823

O-RING

5

708-7T-16460

BALL

6

723-46-15120

RETAINER

7

723-46-14110

SPRING

8

723-46-15111

CASE

9

07430-71380

O-RING

10

01252-30820

BOLT

11

07000-11009

O-RING

12

07000-12021

O-RING

13

07000-12015

O-RING

14

07000-12018

O-RING

15

07000-13032

O-RING

16

07000-03040

O-RING

|17

723-46-48100

VALVE ASS'Y

17

SLEEVE

18

VALVE

19

SEAT

20

POPPET

21

PLUG

22

SCREW

23

NUT

24

NUT

25

SPRING

26

SPRING

27

PLATE

28

CAP

29

SEAL

30

SEAL

31

700-93-11320

O-RING

32

723-46-41950

RING

33

07002-13634

O-RING

34

O-RING

35

RING

36

O-RING

37

RING,BACK-UP

38

01252-60845

BOLT

39

01643-50823

WASHER
