Запчасти Komatsu PC228UU-1-MO ПЕРЕДН. КРЫШКА(COVER) (/) ( АКТУАТОР) (ДЛЯ MONO-СТРЕЛА)(№-7) ЧАСТИ КОРПУСА

|1

22U-54-12372

COVER

1

COVER

2

20Y-54-27123

HINGE

3

22U-54-12712

SHEET

4

22U-54-12721

SHEET

5

22U-54-12730

SHEET

6

22U-54-12740

SHEET

7

22U-54-12751

SHEET

8

22U-54-11322

PLATE

9

20Y-54-27172

U-BOLT

10

22U-54-11192

SEAL

11

01010-81225

BOLT

12

01580-11210

NUT

13

01643-51232

WASHER

14

01010-81230

BOLT

15

01643-31232

WASHER

16

22U-54-11293

BRACKET

17

21Y-54-11180

DAMPER

18

01641-20812

WASHER

19

04052-10833

PIN

20

04205-10830

PIN

21

01010-81230

BOLT

22

01643-31232

WASHER

23

04205-10830

PIN

24

01641-20812

WASHER

25

04052-10833

PIN

26

20T-43-71271

COLLAR

27

01643-31232

WASHER

28

01643-31032

WASHER

29

04050-13020

PIN

30

22U-54-11352

BRACKET

31

01010-81225

BOLT

32

175-54-34170

WASHER

|33

22U-54-12931

COVER

|33

22U-54-12930

COVER

33

22U-54-12941

COVER

|33

22U-54-12940

COVER

34

22U-54-11942

SEAL

35

01010-81225

BOLT

36

01643-31232

WASHER

37

22U-54-12951

COVER

|37

22U-54-12950

COVER

38

01010-81225

BOLT

39

01643-31232

WASHER
