Запчасти Komatsu PC228USLC-8 ГИДР. БАК., (№-) ГИДР. БАК., С РУКОЯТЬ CRANE

1

22U-60-31111

Tank

2

203-60-31100

Elbow Assembly

3

203-60-31160

Tube

4

02783-10628

Elbow

5

07002-12434

O-ring

6

02896-11018

O-ring

7

02782-10522

Elbow

8

07002-12434

O-ring

9

02896-11015

O-ring

10

424-43-37511

Tee

11

07002-11423

O-ring

12

07040-11409

Plug

13

07002-11423

O-ring

14

207-60-71182

Element, Hydraulic Oil Filter

15

20Y-60-31140

Strainer

16

20Y-60-31131

Valve Assembly

17

20Y-60-21240

Spring

18

22U-60-21232

Cover

19

07000-15195

O-ring

20

01010-81230

Bolt

21

01643-31232

Washer

|$21

22U-60-21171

Strainer Assembly

22

22U-60-21181

Rod Assembly

23

20Y-60-21320

Holder

24

12R-60-11230

Spring

25

22B-60-11160

Strainer

26

22U-60-21223

Cover

27

07000-15160

O-ring

28

01010-81230

Bolt

29

01643-31232

Washer

30

22U-60-31120

Cap Assembly

31

20Y-60-21470

Element

32

208-60-71181

Filler Neck

33

20Y-60-21340

Gasket

34

01252-A0516

Bolt, Hexagon Socket Head

35

01601-20513

Washer

36

07285-00220

Clip

37

22U-60-31150

Hose

37

07261-21415

Hose

38

04434-52312

Clip

39

01010-81220

Bolt

40

01643-31232

Washer

41

205-00-73360

Plate, Operating

42

22U-60-27151

Sheet

43

22U-60-31141

Sheet
