Запчасти Komatsu PC228USLC-8 ЦИЛИНДР ОТВАЛА, ЛЕВ. (№-) ЦИЛИНДР ОТВАЛА

Схема запчастей Komatsu PC228USLC-8 - ЦИЛИНДР ОТВАЛА, ЛЕВ. (№-) ЦИЛИНДР ОТВАЛА
26
5
8
1
3
4
2
6
7
9
10
13
15
16
14
17
18
20
21
27
29
31
33
37
11
12
22
23
35
7
35
33
37
23
22
4
24
25
25
28
19
39
41
39
38
40
40
41
34
36
34
36
32
30

Артикул

Название

Примечание

Количество

|$0

22U-63-02550

Cylinder Assembly

1

22U-63-92140

Cylinder

2

22U-63-92120

Rod, Piston

3

707-76-90130

Bushing

4

07145-00090

Seal, Dust, (Kit : K08)

5

07020-00000

Fitting, Grease

6

707-76-10130

Bushing

7

07145-00100

Seal, Dust, (Kit : K08)

8

07020-00000

Fitting, Grease

9

707-27-14920

Head, Cylinder

10

07179-13114

Ring, Snap

11

707-56-10740

Seal, Dust, (Kit : K08)

12

707-52-90781

Bushing

13

707-51-10030

Packing, Rod, (Kit : K08)

14

707-51-10640

Ring, Buffer, (Kit : K08)

15

07000-15130

O-ring, (Kit : K08)

16

707-35-91420

Ring, Back-up, (Kit : K08)

17

01010-81875

Bolt

18

707-41-11840

Washer

19

707-88-32230

Bracket

20

707-36-14410

Piston

21

707-44-14180

Ring, Piston, (Kit : K08)

22

707-39-14820

Ring, Wear, (Kit : K08)

23

707-44-14910

Ring

24

07000-15090

O-ring, (Kit : K08)

25

07001-05090

Ring, Back-up, (Kit : K08)

26

01310-01216

Screw

27

707-81-10150

Collar

28

07000-15100

O-ring, (Kit : K08)

29

707-86-68460

Tube,L.H.

30

02896-11015

O-ring, (Kit : K08)

31

707-86-68480

Tube,L.H.

32

02896-11015

O-ring, (Kit : K08)

33

07372-21060

Bolt

34

01643-51032

Washer

35

07372-21045

Bolt

36

01643-51032

Washer

37

07000-13030

O-ring, (Kit : K08)

38

707-88-31520

Plate

39

07283-32738

Clip, Pipe

40

01643-31032

Washer

41

01597-01009

Nut

Выбрано товаров: 42
