Запчасти Komatsu PC228USLC-8 ЦИЛИНДР СТРЕЛЫ, ПРАВ. (№-) ЦИЛИНДР СТРЕЛЫ, 7MM УСИЛ. СТРЕЛА, 7MM УСИЛ. СТРЕЛА, -НАВЕСН. ОБОРУД, DOZER, С ANTI-DROP КЛАПАН

|$0

707-01-0CE50

Cylinder Assembly

1

721-13-13080

Cylinder

2

707-58-90F60

Rod, Piston

3

707-76-80420

Bushing

4

07145-00070

Seal, Dust, (Kit : K05)

5

707-76-80431

Bushing

6

07145-00080

Seal, Dust, (Kit : K05)

7

707-27-13650

Cylinder Head

8

07179-13104

Ring, Snap

9

707-56-90740

Seal, Dust, (Kit : K05)

10

707-52-90681

Bushing

11

707-51-90030

Packing, Rod, (Kit : K05)

12

707-51-90650

Ring, Buffer, (Kit : K05)

13

07000-15120

O-ring, (Kit : K05)

14

707-35-91320

Ring, Back-up, (Kit : K05)

15

01010-81670

Bolt

16

01643-51645

Washer

17

707-75-90110

Ring, Snap

18

707-36-13780

Piston

19

707-44-13150

Ring, Piston, (Kit : K05)

20

707-39-13150

Ring, Wear, (Kit : K05)

21

707-44-13911

Ring

22

07000-15080

O-ring, (Kit : K05)

23

707-35-90940

Ring, Back-up, (Kit : K05)

24

01310-01216

Screw

25

707-86-68940

Tube

26

707-88-28060

Bracket

27

07372-21060

Bolt

28

01643-51032

Washer

29

07372-21045

Bolt

30

01643-51032

Washer

31

707-88-21331

Band

32

07000-13030

O-ring, (Kit : K05)

33

07372-21035

Bolt

34

01643-51032

Washer

35

07283-32738

Clip, Pipe

36

01597-01009

Nut

37

01643-31032

Washer
